New UMBEL 1.50 Ships With 20 Linked Ontologies

I am proud to announce the immediate release of UMBEL version 1.50. This is a major effort that took a year to release.

What is UMBEL?

Let’s start by explaining what is UMBEL for the ones that never encountered this project before. UMBEL stands for “Upper Mapping and Binding Exchange Layer“. It is a conceptual structure that is designed to help content interoperate between systems.

UMBEL is a coherent general structure of 34 000 reference concepts which provides a scaffolding to link and interoperate other datasets and domain vocabularies. The conceptual structure is organized in a structure of 31 mostly disjoint SuperType.

UMBEL is written in OWL 2 and SKOS.

Continue reading “New UMBEL 1.50 Ships With 20 Linked Ontologies”

Major UMBEL Release: 1.10

After more than 2 years, we are now finally releasing a new version of the UMBEL ontology and reference concept structure. One might think that we haven’t worked on the project all that time, but it is not strictly true. umbel_logo_260_160

We did improve the mapping to external vocabularies/ontologies, we worked much on linking Wikipedia pages to the UMBEL structure, but we haven’t had time to release a new version… until now!

For people new to the ontology, UMBEL is a general reference structure of about 28,000 reference concepts, which provides a scaffolding to link and interoperate other datasets and domain vocabularies. Its main purpose is to have a coherent conceptual structure that we can use to link and interoperate unrelated data sources. But it can also be used as a conceptual structure to be used to describe information like any other ontologies.

What is new with the ontology?

The major change in UMBEL is not the structure itself, but the piece of software used to generate it. In fact, the previous system we developed for generating UMBEL was about 7 years old. It was a bit clunky and really not that easy to work with.

Based on our prior experience with UMBEL, we choose to dump it and to create a brand new UMBEL reference structure generator. This new generator has been developed in Clojure and uses the latest version of the OWL API. It makes the management of the structure much simpler, which means that it will help in releasing new UMBEL version more regularly. We also have a suite of tools to analyze the structure and to pinpoint possible issues.

Other than that, we updated the Schema.org, DBpedia Ontology and Geonames Ontology mappings to UMBEL. This is a major effort undertaken by Mike for this new version. The mappings are composed of:

  • 754 rdfs:subClassOf relationships between Schema.org classes and UMBEL reference concepts
  • 688 rdfs:subClassOf relationships between DBpedia Ontology classes and UMBEL reference concepts
  • 682 rdfs:subClassOf relationships between Geonames Ontology classes and UMBEL reference concepts

These new mappings will help manage data instances that use these external ontologies/schemas in a broader conceptual structure (which is UMBEL). This enables us to be able to reason over this external data using the UMBEL conceptual structure even if these external data sources didn’t originally use UMBEL to describe their data. That is one of the main features of UMBEL.

We also managed to add a few hundred UMBEL reference concepts. Most of them were added to create these new linkages with the external ontologies. Others have been added because they were improving the overall structure.

A few weeks back, we found an issue with the umbel:superClassOf assignations, which has also now been resolved in version 1.10.

In the previous versions of UMBEL, the preferred labels were not unique. There were a few hundred of the concepts that were having the same preferred labels. This was not an issue in itself, but this was not a best practice to create an ontology. We managed to remove all these non-distinct preferred labels and to make all of them unique.

We added a few skos:broader and skos:narrower relationships between some of the reference concepts. In the previous versions, all the relationships were skos:broaderTransitive and skos:narrowerTransitive properties only.

Finally we made sure that the entire UMBEL reference structure (Core + the Geo module) was absent of any inconsistencies and that it was satisfiable.

What is new with the portal and web services?

This new version of UMBEL also led us to create a few new features to the UMBEL website. The most apparent feature is the new External Linkage section that may appear at the top of a reference concept page (obviously, it will not appear if there are no external links for a given reference concept). This section shows you the linkage between the UMBEL reference concept and other external classes:

umbel_linkage_module

Another feature that you will notice on this screenshot is the Core blue tag at the right of the URI of the reference concept. This tag is used to tell you from where the reference concept is coming. Another tag that you may encounter is the green Geo tag, which tells you that the reference concept comes from the UMBEL Geo module. The same tags appear in the search resultsets:

search_modules

What is next?

Because UMBEL is an ontology, by nature it will always evolve over time. Things change, and the way we see the World can always improve.

For the next version of UMBEL, we will analyze the entire UMBEL reference concept structure using different algorithms, heuristics and other techniques to analyze the conceptual structure and to find conceptual gaps in it. The goal of this analysis is to tighten the structure, to have a better conceptual hierarchy and a more fine-grained one.

Other things we want to do in other coming versions are to improve the Super Types structure of UMBEL. As you may know, many of the Super Types are non disjoint because some of the concepts belong to multiple Super Type classes. What we want to do here is to create new Super Types classes that are the intersection between two, or more, Super Types that will be used to categorize these concepts that belong to multiple Super Types. That way, we will end-up with a better classification of the UMBEL reference concepts from a Super Types standpoint.

Another thing we want to do related to the UMBEL web services is to update them such that you can query the linkage to the external ontologies. For now, you can see the linkage when querying the sub-classes and super-classes of a reference concept. But you cannot query the web services this way: give me all the sub-classes-of the http://schema.org/FireStation class, for example.

As you can see, the UMBEL ontology and web services will continue to evolve over time to enable new ways to leverage the conceptual structure and external data sources.

Graph Analysis of a Big Structure: UMBEL

In this blog post, I will show you how we can use basic graph analysis metrics to analyze Big Structures. I will do the analysis of the UMBEL reference concept structure to demonstration how graph and network analysis can be used to better understand the nature and organization of possible issues with Big Structures such as UMBEL. umbel.graph

I will first present the formulas that have been used to perform the UMBEL analysis. To better understand this section, you will need some math knowledge, but there is nothing daunting here. You can probably safely skip that section if you desire.

The second section is the actual analysis of a Big Structure (UMBEL) using the graph measures I presented in the initial section. The results will be presented, analyzed and explained.

After reading this blog post, you should better understand how graph and network analysis techniques can be used to understand, use and leverage Big Structures to help integrate and interoperate disparate data sources.

[extoc]

Big Structure: Big in Size

A Big Structure is a network (a graph) of inter-related concepts which is composed of thousands or even hundred of thousands of such concepts. One characteristic of a Big Structure is its size. By nature, a Big Structure is too big to manipulate by hand and it requires tools and techniques to understand and assess the nature and the quality of the structure. It is for this reason that we have to leverage graph and network measures to help us in manipulating these Big Structures.

In the case of UMBEL, the Big Structure is a scaffolding of reference concepts used to link external (unrelated) structures to help data integration and to help unrelated systems inter-operate. In a World where the Internet Of Things is the focus of big companies and where there are more than 400 standards, such techniques and technologies are increasingly important, otherwise it will end-up being the Internet of [Individual] Things. Such a Big Structure can also be used for other tasks such as helping machine learning techniques to categorize and disambiguate pieces of data by leveraging such a structure of types.

UMBEL as a Graph

UMBEL is an RDF and OWL ontology of a bit more than 26 000 reference concepts. Because the structure is represented using RDF, it means that it is a directed graph. All of UMBEL’s vertices are classes, and all of the edges are properties.

The most important fact to keep in mind until the end of this blog post is that we are manipulating a directed graph. This means that all of the formulas used to analyze the UMBEL graph are formulas applicable to directed graphs only.

I will keep the normal graph analysis language that we use in the literature, however keep in mind that a vertice is a class or a named individual and that a edge is a property.

The UMBEL structure we are using is composed of the classes view and the individuals view of the ontology. That means that all the concepts are there, where some of them only have a class view, others have an individual view and others have both (because they got punned).

Graph Analysis Metrics

In this section, I will present the graph measures that we will use to perform the initial UMBEL graph analysis. In the next section, we will make the analysis of UMBEL using these measures, and we will discuss the results.

This section uses math notations. It could be skipped, but I suggest to try to take time some time to understand each measure since it will help to understand the analysis.

Some Notations

In this blog post, a graph is represented as G = (V,E) where G is the graph, V is the set of all the vertices and E is the set of all the edges of the same type that relates vertices.

The UMBEL analysis focuses on one of the following transitive properties:  rdfs:subClassOf, umbel:superClassOf, skos:broaderTransitive, skos:narrowerTransitive and rdf:type. When we do perform the analysis, we are picking-up a subgraph that is composed of all the connections between the vertices that are linked by this  edge (property).

Density

The first basic measure is the density of a graph. The density measures how many edges are in set E compared to the maximum possible number of edges between vertices in set V. The density is measured with:


 D = \frac{\raisebox{1.5mm}{$\vert E \vert$}}{\raisebox{-1.5mm}{$\vert V \vert ( \vert V \vert \mathbin{-} 1 )$}}


where D is the density, E is the number of properties (edges) and V is the number of classes (vertices).

The density is a ratio of the number of edges that exists, and the number of edges that could exists in the graph. \vert E \vert is the number of edges in the graph and \vert V \vert ( \vert V \vert \mathbin{-} 1 ) is the number of possible maximum number of edges.

The maximum density is 1, and the minimum density is 0. The density of a graph gives us an idea about the number of connections that exists between the vertices.

Average Degree

The degree of a vertex is the number of edges that connect that vertex to other vertices. The average degree of a graph G is another measure of how many edges are in set E compared to number of vertices in set V.


\bar D = \frac{\raisebox{1.5mm}{$\vert E \vert$}}{\raisebox{-1.5mm}{$\vert V \vert$}}


where \bar D is the average degree, E is the number of properties (edges) and V is the number of classes (vertices).

This measure tells the average number of nodes to which any given node is connected.

Diameter

The diameter of a graph G is the longest shortest path between two vertices in the graph. This means that this is the longest path that excludes all detours, loops, etc. between two vertices.

Let d(v_{i},v_{j}) be the length of the shortest path between v_{i} and v_{j}. And v_{i}, v_{j} in V. The diameter of the graph is defined as:


d = max(d(v_{i},v_{j}))


This metric gives us an assessment of the size of the graph. It is useful to understand the kind of graph we are playing with. We will also relate it with the average path length to assess the span of the graph and the distribution of path lengths.

Average Path Length

The average path length is the average of the shortest path length, averaged over all pairs of vertices. Let d(v_{i},v_{j}) be the length of the shortest path between v_{i} and v_{j}. And v_{i}, v_{j} in V.


\bar P =\frac{\raisebox{1.5mm}{$ 1 $}}{\raisebox{-1.5mm}{$ N \cdot (N \mathbin{-} 1) $}} \cdot \sum_{i \neq j}^{} d(v_{i},v_{j})


where, N is the number of vertices in the graph G; where, N \cdot (N \mathbin{-} 1) is the number of pairs of distinct vertices. Note that the number of pairs of distinct vertices is equal to the number of shortest paths between all pairs of vertices if we pick just one in case of a tie (two shortest paths with the same length).

In the context of ontology analysis, I would compare this metric as the speed of the ontology. What I mean by that is that one of the main tasks we do with an ontology is to infer new facts from known facts. Many inferring activities requires traversing the graph of an ontology. This means that the smaller the average path length between two classes, the more performant these inferencing activities should be.

Average Local Clustering Coefficient

The local clustering coefficient quantifies how well connected the neighborhood vertices of a given vertex are. It is the ratio of the edges that exists between all of the neighborhood vertices of a given vertex and the maximum number of possible edges between these same neighborhood vertices.


C_{i} = \frac{\raisebox{1.5mm}{$\vert \lbrace e_{jk} : v_{j}, v_{k} \in N_{i}, e_{jk} \in E \rbrace \vert$}}{\raisebox{-1.5mm}{$k_{i} (k_{i} \mathbin{-} 1 $}}


where k_{i} is the number of neighborhood vertices, $k_{i} (k_{i} \mathbin{-} 1 $}) is the maximum number of edges between the neighborhood vertices and \vert \lbrace e_{jk} : v_{j}, v_{k} \in N_{i}, e_{jk} \in E \rbrace \vert is the set of all the neighborhood vertices for a given vertex e_{jk}.

The local clustering coefficient \bar C is represented by the sum of the clustering coefficient of all the vertices of a graph G divided by the number of vertices in G. It is given by:


\bar C = \sum_{i=1}^{n} \frac{C_{i}}{n}

Betweenness Centrality

Betweenness centrality is a measure of importance of a node in a graph. It is represented by the number of times a node participates in the shortest path between other nodes. If a node participates in the shortest path of multiple other nodes, then it means that it is more important than other nodes in the graph. It acts like a conduit.


g(v) = \sum_{s \neq v \neq t}^{} \frac{\raisebox{1.5mm}{$\sigma_{st}(v)$}}{\raisebox{-1.5mm}{$\sigma_{st}$}}


where \sigma_{st} is the total number of shortest paths from node s to node t and \sigma_{st}(v) is the number of those paths that pass through v.

In the context of ontology analysis, the betweenness centrality will tell us which of the classes that participates the more often in the shortest paths of a given transitive property between other classes. This measure is interesting to help us understand how a subgraph is constructed. For example, if we take a transitive property such as rdfs:subClassOf, then the graphs generated by a subgraph composed of this relationship only should be more hierarchic by the semantic nature of the property. This means that the nodes (classes) with the highest betweenness centrality value should be classes that participate in the upper portion of the ontology (the more general classes). However, if we think about the foaf:knows transitive property between named individuals, then the results should be quite different and suggest a different kind of graph.

Initial UMBEL Graph Analysis

Now that we have a good understanding of some core graph analysis measures, we will use them to analyze the graph of relationship between the UMBEL classes and reference concepts using the subgraphs generated by the properties: rdfs:subClassOf, umbel:superClassOf, skos:broaderTransitive, skos:narrowerTransitive and rdf:type.

Density

The maximum number of edges in UMBEL is: 26 345 * (26 345 - 1) = 694 032 680 which is about two thirds of a billion of edges. This is quite a lot of edges, but it is important to keep in mind since most of the following ratios are based on this maximum number of edges (connections) between the nodes of the UMBEL graph.

Here is the table that shows the density of each subgraph generated by each property:

Class view Individual view
Metric sub class of super class of broader narrower type
Number of edges 39 410 116 792 36 016 36 322 271 810
Density 0.0000567 0.0001402 0.0000518 0.0000523 0.0001021

As you can see, the density of any of the UMBEL subgraphs is really low considering that the maximum density of the graph is 1. However this gives us a picture of the structure: Most of the concepts have no more than few connections between each node for any of the analyzed properties.

This makes sense, since a conceptual structure is meant to model relationships between concepts that represent concepts of the real world, and in the real world, the concepts that we created are far from being connected to every other concept.

This is actually what we want: we want a conceptual structure which has a really low density. This suggest that the concepts are unambiguously related and hierarchized.

Having a high density (let’s say, 0.01, which would mean that there are nearly 7 million connections between the 26 345 concepts for a given property) may suggest that the concepts are too highly connected which could suggest that using the UMBEL ontology for tagging, classifying and reasoning over its concepts won’t be an optimal choice because of the nature of the structure and its connectivity (and possible lack of hierarchy).

Average Degree

The average degree shows the average number of UMBEL nodes that are connected to any other node for one of the given property.

Class view Individual view
Metric sub class of super class of broader narrower type
Number of Edges 39406 97323 36016 36322 70921
Number of Vertices 26345 26345 26345 26345 26345
Average degree 1.4957 3.6941 1.3670 1.3787 2.6920

As you can see, the number are quite low: from 1.36 to 3.69. This is consistent with what we saw with the density measure above. This helps confirm our assumption that all of these properties create mostly hierarchical subgraphs.

However there seems to be one anomaly with these results, the average degree 3.69 of the umbel:superClassOf property. Intuitively, its degree should be near the one of the rdfs:subClassOf but it is far from this: it is more than twice its average degree. Looking at the OWL serialization of the UMBEL version 1.05 reveals that most umbel:RefConcept do have 3 triples:

  umbel:superClassOf skos:Collection ,
                     skos:ConceptScheme ,
                     skos:OrderedCollection .

This makes no sense that the umbel:RefConcept are super classes of these skos classes. I suspect that this got introduced via punning at some point in the history of UMBEL and got unnoticed until today. This issue will be fixed in a coming maintenance version of UMBEL.

If we check back the density measure of the graph, we notice that we have a density of 0.0001402 for the umbel:superClassOf property versus 0.0000567 for the rdfs:subClassOf property which has about the same ratio. So we could have noticed the same anomaly by taking a better look at the density measure.

But in any case, this shows how this kind of graph analysis can be used to find such issues in Big Structures (structures too big to find all these issues by scrolling the code only).

Diameter

The diameter of the UMBEL graph is like the worse case scenario. It tells us what is the longest shortest path for a given property’s subgraph.

Class view Individual view
Metric sub class of super class of broader narrower type
Diameter 19 19 19 19 4

In this case, this tell us that the longest shortest path between two given nodes for the rdfs:subClassOf property is 19. So in the worse case, if we infer something between these two nodes, then our algorithms will require maximum 19 steps (think in terms of a breath first search, etc).

Average Path Length Distribution

The average path length distribution shows us the a number paths that have x in length. Because of the nature of UMBEL and its relationships, I think we should expect a normal distribution. An interesting observation we can do is the the average path length is situated around 6, which is the six degree of separation.

We saw that the “worse case scenario” was a shortest path of 19 for all the property except rdf:type. Now we know that the average is around 6.

rdfs:SubClassOf

umbel-sub-class-of-transitive-paths-distribution

umbel:superClassOf

umbel-super-class-of-transitive-paths-distribution

Here we can notice an anomaly in the expected normal distribution of the path lengths. Considering the other analysis we did, we can consider that the anomaly is related to the umbel:superClassOf issue we found. What we will have to re-check this metric once we fix the issue. I expect we will see a return to a normal distribution.

skos:broaderTransitive

umbel-skos-broader-transitive-paths-distribution



skos:narrowerTransitive

umbel-narrower-transitive-transitive-paths-distribution



rdf:type

umbel-type-transitive-paths-distribution



Average Local Clustering Coefficient

The average local clustering coefficient will tell us how clustered the UMBEL subgraphs are.

Class view Individual view
Metric sub class of super class of broader narrower type
Average local clustering coefficient 0.0001201 0.00000388 0.03004554 0.00094251 0.77191429

As we can notice, UMBEL does not have the small-world effect with its small clustering coefficients depending on the properties we are looking at. It means that there is not a big number of hubs in the network and so that the number of steps from going from a class or a reference concept to another is higher than in other kinds of networks, like airport networks. This makes sense by looking at the average path length and the path length distributions we observed above.

At the same time, this is the nature of the UMBEL graph: it is meant to be a a well structured set of concepts with multiple different specificity layers.

To understand its nature, we could consider the robustness of the network. Normally, networks with high average clustering coefficients are known to be robust, which means that if a random node is removed, it shouldn’t impact the average clustering coefficient or the average path length of that network. However, in a network that doesn’t have the small-world effect, then they are considered less robust which means that if a node is removed, it could greatly impact the clustering coefficients (which would be lower) and the average path length (which would be higher).

This makes sense in such a conceptual network: if we remove a concept from the structure, it will most than likely impact the connectivity of the other concepts of the network.

One interesting thing to notice is the clustering coefficient of 0.03 for the skos:broaderTransitive property and 0.00012 for the rdfs:subClassOf property. I have no explanation for this discrepancy at the moment, but this should be investigated after the fix as well since intuitively these two coefficient should be close.

Betweenness Centrality

As I said above, In the context of ontology analysis, the betweenness centrality tells us which of the classes participates more often in the shortest paths of a given transitive property between other classes. This measure is useful to help us understand how a subgraph is constructed.

If we check the results below, we can see that all the top nodes are nodes that we could easily classify as being part of the upper portion of the UMBEL ontology (the general concepts). Another interesting thing to notice is that the issue we found with the umbel:superClassOf property doesn’t seem to have any impact on the betweenness centrality of this subgraph.

rdfs:subClassOf
PartiallyTangible 0.1853398395065167
HomoSapiens 0.1184076250864128
EnduringThing_Localized 0.1081317879905902
SpatialThing_Localized 0.092787668995485
HomoGenus 0.07956810084399618

You can download the full list from here

umbel:superClassOf
PartiallyTangible 0.1538140444614064
HomoSapiens 0.1053345447606491
EnduringThing_Localized 0.08982813055659158
SuperType 0.08545549956197795
Animal 0.06988077993945754

You can download the full list from here

skos:broaderTransitive
PartiallyTangible 0.2051286996513612
EnduringThing_Localized 0.1298479341295156
HomoSapiens 0.09859060900526667
Person 0.09607892589570508
HomoGenus 0.08806468362881092

You can download the full list from here

skos:narrowerTransitive
PartiallyTangible 0.2064665713447941
EnduringThing_Localized 0.1294085106511612
HomoSapiens 0.1019893654646639
Person 0.09366129700219764
HomoGenus 0.09047063411213117

You can download the full list from here

rdf:type
owl:Class 0.3452564052004049
RefConcept 0.3424169525837704
ExistingObjectType 0.0856962574437039
ObjectType 0.01990245954437302
TemporalStuffType 0.01716817183946576

You can download the full list from here

Analysis with Inferred UMBEL

Now, let’s push the analysis further. Remember that I mentioned that all the properties we are analyzing in this blog post are transitive? Let’s perform exactly the same metrics analysis, but this time we will use the transitive closure of the subgraphs.

The transitivity characteristic of a property is simple to understand. Let’s consider this tiny graph A \xrightarrow{p^{t}} B \xrightarrow{p^{t}} C where the property \xrightarrow{p^{t}} is a transitive property. Since \xrightarrow{p^{t}} is transitive, there is also a relationship A \xrightarrow{p^{t}} C.

Given A \xrightarrow{p^{t}} B \xrightarrow{p^{t}} C we inferred A \xrightarrow{p^{t}} C using the transitive relation \xrightarrow{p^{t}}.

Now, let’s use the power of these transitive properties and let’s analyze the transitive closure of the subgraphs that we are using to compute the metrics. The transitive closure is simple to understand. From the input subgraph, we are generating a new graph where all these transitive relations are explicit.

Let’s illustrate that using this small graph: A \xrightarrow{p^{t}} B \xrightarrow{p^{t}} C, B \xrightarrow{p^{t}} D. The transitive clojure would create a new graph: A \xrightarrow{p^{t}} B \xrightarrow{p^{t}} C, B \xrightarrow{p^{t}} D, A \xrightarrow{p^{t}} C, A \xrightarrow{p^{t}} D

This is exactly what we will be doing with the sub-graphs created by the properties we are analyzing in this blog post. The end result is that we will be analyzing a graph with many more edges than we previously had with the non transitive closure versions of the subgraphs.

What we will analyze now is the impact of considering the transitive closure upon the ontology metrics analysis.

Density

Remember that the maximum number of edges in UMBEL is: 26 345 * (26 345 - 1) = 694 032 680, which is about two thirds of a billion edges.

Class view Individual view
Metric sub class of super class of broader narrower type
Number of Edges 789 814 922 328 674 061 661 629 76 074
Density 0.0011380 0.0013289 0.0009712 0.0009533 0.0001096

As we can see, we have many more edges now with the transitive closure. The density of the graph is higher as well since we inferred new relationships between nodes from the transitive nature of the properties. However it is still low considering the number of possible edges between all nodes of the UMBEL graph.

Average Degree

We now see the impact of transitive closure on the average degree of the subgraphs. Now each node of the subgraphs are connected by 25 to 35 other nodes in average.

Class view Individual view
Metric sub class of super class of broader narrower type
Number of Edges 789 814 922 328 674 061 661 629 76 074
Number of Vertices 26345 26345 26345 26345 26345
Average degree 29.97965 35.00960 25.58591 25.11402 2.887606

One interesting fact is that the anomaly disappears with this transitive closure subgraph for the umbel:superClassOf property. There is still a glitch with it, but I don’t think it would raise suspicion at first. This is important to note since we won’t have noticed this issue with the current version of the UMBEL ontology if we would have analyzed the transitive closure of the subgraph only.

Diameter

Class view Individual view
Metric sub class of super class of broader narrower type
Diameter 2 2 2 2 2

As expected, the diameter of any of the transitive closure subgraphs is 2. It is the case since we made explicit a fact (a edge) between two nodes that was not explicit at first. This is good, but this is no quite useful from the perspective of ontology analysis.

This would only be helpful if the number were not 2 which would suggest some errors in the way you computed the diameter of the graph.

However what we can see here is that the speed of the ontology (as defined in the Average Path Length section above) is greatly improved. Since we forward-chained the facts in the transitive closure sub-graphs, it means that knowing if a class A is a sub-class of a class B is much faster, since we have a single lookup to do instead of an average of 6 for the non transitive closure version of the subgraphs.

Average Path Length Distribution

All of the path length distributions will be the same as this one:

umbel-sub-class-of-transitive-paths-distribution-inferredSince the diameter is 2, then we have a full lot of paths at 2, and 26 345 at 1. This is not really that helpful from the standpoint of ontology analysis.

Average Local Clustering Coefficient

Class view Individual view
Metric sub class of super class of broader narrower type
Average local clustering coefficient 0.3281777 0.0604906 0.2704963 0.0138592 0.7590267

Some of the properties like the rdfs:subClassOf property shows a much stronger coefficient than with the non-transitive closure version. This is normal since all the nodes are connected to the other nodes down the paths. So, if a node in between disappears, then it won’t affect the connectivity of the subgraph since all the linkage that got inferred still remains.

This analysis also suggests that the transitive closure version of the subgraphs are much stronger (which makes sense too).

However I don’t think this metric is that important of a characteristic to check when we analyze reference ontologies since they do not need to be robust. They are not airport or telephonic networks that need to cope with disappearing nodes in the network.

Betweenness Centrality

What the betweenness centrality measure does with the transitive closure of the subgraphs is that it highlight the real top concepts of the ontology like Thing, Class, Individual, etc. Like most of the other measures, it blurs the details of the structure (which is not necessarily a good thing).

rdfs:subClassOf
SuperType 0.03317996389023238
AbstractLevel 0.02810408526564482
Thing 0.02772171675862925
Individual 0.02747482318621853
TopicsCategories 0.02638342698407473

You can download the full list from here

umbel:superClassOf

The interesting thing here is that this measure actual shows the actual concepts for which we discovered an issue with above.

skos:Concept 0.02849203320293865
owl:Thing 0.02849094898994718
SuperType 0.02848878056396423
skos:ConceptScheme 0.02825567477079737
skos:OrderedCollection 0.02825567477079737

You can download the full list from here

skos:broaderTransitive
Thing 0.03225428380683926
Individual 0.03196350419108375
Location_Underspecified 0.0261924189600178
Region_Underspecified 0.02618796825161338
TemporalThing 0.02594169571990208

You can download the full list from here

skos:narrowerTransitive
Thing 0.03298126713602109
Location_Underspecified 0.02680852092899528
Region_Underspecified 0.02680398659044947
TemporalThing 0.02648809433842489
SomethingExisting 0.02582305801837314

You can download the full list from here

rdf:type
owl:Class 0.3452564052004049
RefConcept 0.342338078899975
ExistingObjectType 0.0856962574437039
ObjectType 0.01990245954437302
TemporalStuffType 0.01716817183946576

You can download the full list from here

Conclusion

This blog post shows that simple graph analysis metrics applied to Big Structures can be quite helpful to understand their nature, how they have been constructed, what is their size, their impact on some algorithms that could use them, and to find potential issues in the structure.

One thing we found is that the correlation between the properties rdfs:subClassOf and skos:broaderTransitive are nearly identical. They nearly have the same values for each metrics. If you were new to the UMBEL ontology you wouldn’t have known this fact without doing this kind of analysis or by spending much time looking at the serialized OWL file. It doesn’t tell us anything about how similar the relations are, but it does tell us that they have the same impact on the ontology’s graph structure.

Performing this analysis also led us to discover a few anomalies with the umbel:superClassOf property, suggesting an issue with the current version of the ontology. This issue would have been hard to notice, and understand, without performing such a graph analysis to the structure.

However, I also had the intuition that the analysis of the transitive closure of the subgraphs would have led to more interesting results. At best that analysis did confirm a few things, but in most of the cases it only blurred the specificities of most of the metrics.

These analysis metrics will soon be made available as standard Web services, so that they may be applied against any arbitrary graph or ontology.

UMBEL: New Shortest Path Web Service & Tag Web Documents

We just released a new UMBEL ontology graph analysis web service endpoint: the Shortest Path web service endpoint. umbel_ws

The Shortest Path Web service is used to get the shortest path between two UMBEL reference concepts by following the path of a transitive property. The concepts that belong to that path will be returned by the server.

This web service is similar to the degree web service endpoint but the actual path is shown. This web service is (marginally more useful) than degree. So if you don’t need to know the actual concepts that participate in the shortest path between two concepts, then you should be using the degree web service endpoint instead.

The graph created by the UMBEL reference concepts ontology is a mostly an directed acyclic graph (DAG). This means that a given pair of concepts is not necessarily linked via all the properties. In these cases, the shortest path returns an error message rather than the path concepts.

Intended Users

This new web service endpoint is intended for users that want to perform graph/network analysis tasks on the UMBEL web service endpoint.

The Web Service Endpoint

The web service endpoint is freely available. It can return its resultset in JSON or in EDN (Extensible Data Notation).

This endpoint will return a vector (so the order of the results is important) of concepts that participate into the shortest path. For each concept, its URI and preferred label are returned.

The Online Tool

We also provide an online shortest path tool that people can use to experience interacting with the web service.

The user first needs to select the two concepts for which he wants to find the shortest path between the two. Then he has to select the transitive property he want to use to find the path.

Once the user clicks the Get Shortest Path button, he will get list of concepts, and the order, that compose the path.

If no path exists between the two concepts for the selected property, an error message is displayed to the user.


shortest-path-ui

Tagging Web Documents with the UMBEL Taggers

Another improvement included with this release is the enhancement of the UMBEL taggers12. It is now possible to tag any document accessible on the Web. The only thing you have to do is to provide a URL where the tagger will find the document to download and tag.

The user interface for the taggers also was modified to expose this new functionality. You now have the choice to give a text or a URL as input to the endpoints:


new-tagging-ui

New UMBEL Concept Noun Tagger Web Service & Other Improvements

Last week, we released the UMBEL Concept Plain Tagger web service endpoint. Today we are releasing the UMBEL Concept Noun Tagger. umbel_ws

This noun tagger uses UMBEL reference concepts to tag an input text, and is based on the plain tagger, except as noted below.

The noun tagger uses the plain labels of the reference concepts as matches against the nouns of the input text. With this tagger, no manipulations are performed on the reference concept labels nor on the input text except if you specify the usage of the stemmer. Also, there is NO disambiguation performed by the tagger if multiple concepts are tagged for a given keyword.

Intended Users

This tool is intended for those who want to focus on UMBEL and do not care about more complicated matches. The output of the tagger can be used as-is, but it is intended to be the input to more sophisticated reference concept matching and disambiguation methods. Expect additional tagging methods to follow.

Stemming Option

This web service endpoint does have a stemming option. If the option is specified, then the input text will be stemmed and the matches will be made against an index where all the preferred and alternative labels have been stemmed as well. Then once the matches occurs, the tagger will recompose the text such that unstemmed versions of the input text and the tagged reference concepts are presented to the user.

Depending on the use case. users may prefer turning on or off the stemming option on this web service endpoint.

The Web Service Endpoint

The web service endpoint is freely available. It can return its resultset in JSON, Clojure code or EDN (Extensible Data Notation).

This endpoint will return a list of matches on the preferred and alternative labels of the UMBEL reference concepts that match the noun tokens of an input text. It will also return the number of matches and the position of the tokens that match the concepts.

The Online Tool

We also provide an online tagging tool that people can use to experience interacting with the web service.

The results are presented in two sections depending on whether the preferred or alternative label(s) were matched. Multiple matches, either by concept or label type, are coded by color. Source words with matches and multiple source occurrences are ranked first; thereafter, all source words are presented alphabetically.

The tagged concepts can be clicked to have access to their full description.

umbel_tagger_noun

Other UMBEL Website Improvements

We also did some more improvements to the UMBEL website.

Search Autocompletion Mode

First, we created a new autocomplete option on the UMBEL Search web service endpoint. Often people know the concept they want to look at, but they don’t want to go to a search results page to select that concept. What they want is to get concept suggestions instantly based on the letters they are typing in a search box.

Such a feature requires a special kind of search which we call an “autocompletion search”. We added that special mode to the existing UMBEL search web service endpoint. Such a search query takes about 30ms to process. Most of that time is due to the latency of the network since the actual search function takes about 0.5 millisecond the complete.

To use that new mode, you only have to append /autocomplete to the base search web service endpoint URL.

Search Autocompletion Widget

Now that we have this new autocomplete mode for the Search endpoint, we also leveraged it to add autocompletion behavior on the top navigation search box on the UMBEL website.

Now, when you start typing characters in the top search box, you will get a list of possible reference concept matches based on the preferred labels of the concepts. If you select one of them, you will be redirected to their description page.

concept_autocomplete

Tagged Concepts Within Concept Descriptions

Finally, we improved the quality of the concept description reading experience by linking concepts that were mentioned in the descriptions to their respective concept pages. You will now see hyperlinks in the concept descriptions that link to other concepts.

linked_concepts
